XL3 Acoustic Analyzer

Switch On. Measure. Analyze.

  • Sound Level Meter
  • Spectrum Analyzer
  • STIPA Analyzer
  • Audio Analyzer
  • Vibration Meter

Download PDFs

ENQUIRY FOR MORE DETAILS:

The Hand-Held Xl2 Analyzer Is A Powerful Sound Level Meter, A Professional Acoustic Analyzer, A Precision Audio Analyzer And A Comprehensive Vibration Meter In One Instrument. Easy Operation And Countless Applications Distinguish This Quality Swiss Product. The Xl2 Sound Level Meter Is Available In Stock, Allowing For Expedited Delivery.

At a glance

  • Reliable measurement solution
  • Flexible user interface
  • Extensive range of measurement functions

The Xl2 As A Sound Level Meter

Numerous measurement variations are simultaneously available. Actual level (live), Lmin, Lmax, Leq and Lpeak may be measured in combination with frequency weighting A, C or Z and time weightings fast, slow and impulse. All results are simultaneously available and may be stored automatically for later documentation.

Customers may log all acquired level information onto a removable SD card. Additionally the XL2 offers wav-file recording for a complete documentation of the measured sound pressure levels. Voice notes may also be added to each measurement.

The Xl2 As A Sound Level Meter

Sound Level Meter Features

  • IEC 61672, IEC 60651, IEC 60804, IEC 61260
  • China: GB/T 3785:2010, GB/T 3241, GB 3096-2008, GB 50526, GB-T_4959-1995
  • Germany: DIN 15905-5, DIN 45645-2, optional: DIN 45645-1
  • Japan: JIS C1509-1:2005, JIS C 1513 class 1, JIS C 1514 class 0
  • Switzerland: SLV
  • UK: BS6698, BS5969
  • US: ANSI S1.4:2014, ANSI S1.43, ANSI S1.11:2014
  • SMPTE ST 202:2010, ISO 2969:2015
The XL2 as a Real Time Analyzer RTA

The XL2 as a Real Time Analyzer RTA

The RTA perfectly suits tasks such as optimization of sound systems and rooms.
The XL2 measures and logs wideband values and the real time spectrum in 1/1 or 1/3 octave-band resolution according to IEC 61260 class 0. The sound level meter results of the wideband and RTA spectrum are simultaneously available.

Real Time Analyzer Features

  • 1/3 octave, 1/1 octave
  • Frequency weighting: A, C, Z (=flat)
  • Time weighting: Fast, slow and optional impulse
  • Percentile statistics for Lxy (x= A, C or Z, y= F or S ): 1 – 99%
    (optional)

XL2 Performance & Functional Overview

Switch On - Good To Go

Switch On - Good To Go

Get the job done, on time! The instrument is ready to measure literally seconds after you press the power button. The intuitive navigation and flexible user interface assist in simplifying every task. The XL2 provides an extensive range of measurement functions.

Ready For Any Challenge

The XL2 is developed according to user needs, and provides reliable measurement solutions for sound system installations, noise control, architectural acoustics, evacuation systems, live events, quality inspection and occupational health and safety. Discover an instrument you can trust for specialist applications.

5 Reasons Why The Xl2 Is The Right Choice For You

The XL2 Acoustic Analyzer offers numerous measurement functions relevant to your application in one instrument. Thanks to the intuitive operation, you can quickly and easily switch between the different measuring functions.

Real Time Analyzer Features

  • The intuitive user interface makes operation child’s play without having to study the user manual.
  • Rugged and ready for tough environments.
  • All measurement results are stored on a removable SD card as TXT files, which can be further processed externally with a PC or MAC.
  • The XL2 has many expandable measurement functions. So, if you have other acoustic or audio measurement tasks, it’s likely that the XL2 can help you.
  • Together with the Type Approval Option, the XL2 is an approved Sound Level Meter.
5 Reasons Why The Xl2 Is The Right Choice For You
Incomparable Value

Incomparable Value

The XL2 Audio and Acoustic Analyzer provides top-class performance with excellent value for money. You will receive an instrument exactly tailored to your needs for less than you expect.

Data Analysis And Reporting

The XL2 stores all data onto the SD card for direct transfer to the computer. Data reports and log files are stored in plain text format, which can be opened with any text editor (Notepad, Wordpad, etc). The data is tab-delimited, so dropping the .txt file into a spreadsheet application will conveniently show the results in columns. The sound level meter may additionaly record the audio data as a WAV-file . A series of free MS Excel application templates provide a convenient way to view the measurement results of specific tasks and create simple reports.

Free Reporting Tools:

  • Basic Live Sound and Noise Monitoring Reporting
  • Noise Exposure
  • Speech Intelligibility Reporting
DOWNLOAD HERE

Professional Software Packages (optional):

Data Explorer
Professional solution for a comprehensive analysis of logged noise monitoring data. The data import into the software is enabled by the Data Explorer Option or the annual subscription service Data Explorer 365.Data Explorer
Professional solution for a comprehensive analysis of logged noise monitoring data. The data import into the software is enabled by the Data Explorer Option or the annual subscription service Data Explorer 365.Data Explorer
Professional solution for a comprehensive analysis of logged noise monitoring data. The data import into the software is enabled by the Data Explorer Option or the annual subscription service Data Explorer 365.Data Explorer
Professional solution for a comprehensive analysis of logged noise monitoring data. The data import into the software is enabled by the Data Explorer Option or the annual subscription service Data Explorer 365.
